Power Driven Diesel P7100 Injection Pumps

12-Valve Cummins | P-Pumped Applications

All pumps listed below are fully rebuilt with new seals, calibrated to spec, and require a core return.
Core return labels apply to the Lower 48 only.
Build times vary — please call for lead times.

Stage 1 P7100 – Tow Series

Up to 500 HP | 325–350cc

The Stage 1 Tow Series P7100 Injection Pump is designed specifically for heavy towing and daily-driven reliability. This pump prioritizes smooth fuel delivery, strong low-RPM torque, and controlled EGTs under load.

Key Features:

• Fully rebuilt with all-new seals

• AFC Max Travel Kit

• Upgraded 35+ PSI AFC Spring

• Power Driven 4K Governor Springs

• Power Driven 055 Delivery Valves

• Power Driven AFC Foot

• Pin timed to 18°

• Black painted finish

Performance:

• 325–350cc max fuel

• Rated up to 500 HP

• Excellent towing manners and drivability

Core Required: Yes

Stage 2 P7100 – Street / Tow Series

Up to 650 HP | 420–450cc

The Stage 2 Street/Tow P7100 is the perfect balance between street performance and towing capability. Designed to deliver increased fueling while maintaining smooth and predictable power delivery, this pump is ideal for trucks that work hard but still want strong performance.

Key Features:

• Fully rebuilt with all-new seals

• AFC Max Travel Kit

• Upgraded 35+ PSI AFC Spring

• Power Driven 4K Governor Springs (4,000 RPM)

• Power Driven 025 Delivery Valves

• Power Driven AFC Foot

• Pin timed to 18°

• Black painted finish

Performance:

• 420–450cc max fuel

• Rated up to 650 HP

• Excellent towing control with strong street performance

Core Required: Yes

Stage 3 P7100 – Hot Street / Race Series

650–1000 HP | Up to 700cc

The Stage 3 P7100 Injection Pump is built for enthusiasts looking for serious power without sacrificing street manners. Designed, tested, and calibrated to maximize fuel delivery while maintaining excellent smoke control, this pump is a proven performer for high-output street trucks.

Key Features:

• Built exclusively on a 215 HP P7100 core

• Fully rebuilt with all-new seals

• AFC Max Travel Kit

• Upgraded 35+ PSI AFC Spring

• Power Driven Rack Plug

• Power Driven 4K Governor Springs

• Power Driven 025 Delivery Valves

• Power Driven AFC Foot

• Precision 18° pin timing

• Black cherry paint finish

Performance:

• Up to 650–700cc fueling

• Capable of supporting up to 1000 HP

• Excellent smoke control and streetability

Core Policy:

• 215 HP core required for full refund

• 180 HP cores: up to $1500 refund

• 160 / 175 HP cores: up to $1000 refund

13mm P7100 – Full Race Pump

1000–1600+ HP | 900–950cc

This 13mm P7100 Injection Pump is built for full race and competition use only. Designed to support extreme horsepower levels, this pump is maxed, balanced, and assembled using genuine Bosch components. This is not a street pump.

🚨 WILL NOT SHIP WITHOUT CORE FEE PAID

Includes:

• Bosch 13mm barrels and plungers

• Hamilton V2.75 billet cam

• Hamilton tappet springs

• 5,000 RPM or open RPM auto governor

• 025 delivery valves or full cuts

• Open delivery valve holders

• Maxed and balanced calibration

• Genuine Bosch internal components

Performance:

• 900–950cc max fuel

• Supports 1000–1600+ HP

• Requires minimum 5x.022 injectors

Additional Info:

• Built with new gaskets and seals

• Includes flow sheet and build sheet

• 1-year warranty

• Typical lead time: 5–8 weeks

Core Required:

• Requires 215 HP or 180 HP P7100 core

Accepted Bosch 10-Digit Core Part Numbers

Eligible for full or partial credit:

• 0 402 736 913

• 0 402 736 887

• 0 402 736 911

• 0 402 736 885

• 0 402 736 841

• 0 402 736 854

• 0 402 736 912

• 0 402 736 899

• 0 402 736 844

$1000 Core Credit Only:

• 0 402 736 846

• 0 402 736 847

• 0 402 736 848

• 0 402 736 838
